Thread-tapping in metal
MEPLAST
An optimized plastic flow reduces the load on the nut material and allows a plastic-compatible connection. The high thread coverage ensures a larger shear surface. This increases the overtorque of the connection.
Features
- Suitable for all types of plastics
- 30° flank angle
- Various head shapes depending on the application
- Most cost-effective direct fastening
- Vibration-resistant and self-locking
Features
-Suitable for all types of plastics
-Innovative thread flank geometry for optimal material forming and increased flank coverage
-Significantly longer service life of the connection under static and dynamic loads
-Up to 50% higher tensile and torsional strength at the same nominal diameter
-Optimized geometry allows for shorter screws and smaller diameters
-Enlarged head diameter effectively reduces surface pressure
-Increased minimum breaking torque
-MEPLAST 30 D retains all technical properties of the MEPLAST 30 screw
Thread-tapping in metal
MEPTITE
MEPTITE allows you to join metal applications without the need for thread cutting or additional securing elements.
Advantages
- No more time-consuming thread cutting
- Chipless forming
- Full thread flank coverage
- Play-free seat
- Enormous Holding Power
- High back torque
- Quick assembly
- High time savings
- Cost savings
Applications
- Plant and mechanical engineering
- Vehicle substructure
- Transport system construction
- Rail vehicles
- Engine mounts
- Load-bearing structures
The Menschel Autopilot for difficult installation situations
ME-FIND
The use of the ME-FIND tip ensures that the screw aligns itself when screwed in before the thread meets the counter thread.
Advantages
- No license fee required
- No special production tools required
- Fewer errors and waste
- Reduced downtime
Characteristics
- Self-aligning screw prevents cross threading
- Possibility to correct misalignment errors up to 0.6 times the nominal diameter
- Prevents cross thread cutting up to 20°
- All metric screws can be equipped with the ME-FIND tip
safety screws with anti-loosening device
ME-RIPP
ME-RIPP is a mechanically acting screw with flange head/external hexagon and locking ribs for sensitive surfaces
Advantages
- Many dimensions and surfaces available immediately
- Reliable anti-loosening device
- Retention of the preload force even under high dynamic loads
- Eliminates washers, spring washers or other additional safety devices
Applications
- Mechanical engineering
- Shipbuilding
- Cranes
- Vehicle bodies (trucks, tracked vehicles)
- Rail vehicles
- Engine mounts
safety screws with anti-loosening device
ME-ZAHN
ME-ZAHN is a mechanically acting screw with flange head/external hexagon and locking teeth
Advantages
- Reliable anti-loosening device
- Retention of the preload force even under high dynamic loads
- Eliminates washers, spring washers or other additional safety devices
Applications
- Mechanical engineering
- Shipbuilding
- Cranes
- Vehicle bodies (trucks, tracked vehicles)
- Rail vehicles
- Engine mounts
